| TECHNICAL DATA | |
| Material: | 304/316L/HT200 |
| DN: | 20mm-300mm |
| PN: | 16bar |
| Q: | 2m³/h-1000m³/h |
| H: | 5m-80m |
| T: | -50°C-260°C |
| P: | 0.37kw-250kw |
Send E-mail:Nancy@jnhgbf.com
| N | Model | Rev =2900r/min Medium density=1000kg/m³ | ||||||
| Flow | Pump head | η | Inlet | Outlet | Npsh | Power | ||
| (m³/h) | (m) | (%) | (mm) | (mm) | (m) | (kw) | ||
| 1 | IH50-32-125 | 12.5 | 20 | 52 | φ50 | φ32 | 3 | 2.2 |
| 2 | IH50-32-160 | 12.5 | 32 | 46 | φ50 | φ32 | 3.5 | 4 |
| 3 | IH50-32-200 | 12.5 | 50 | 40 | φ50 | φ32 | 3.5 | 7.5 |
| 4 | IH50-32-250 | 12.5 | 80 | 38 | φ50 | φ32 | 3.5 | 11 |
| 5 | IH65-50-125 | 25 | 20 | 63 | φ65 | φ50 | 3.5 | 3 |
| 6 | IH65-50-160 | 25 | 32 | 58 | φ65 | φ50 | 3.5 | 5.5 |
| 7 | IH65-40-200 | 25 | 50 | 53 | φ65 | φ40 | 3.5 | 11 |
| 8 | IH65-40-250 | 25 | 80 | 49 | φ65 | φ40 | 3.5 | 18.5 |
| 9 | IH80-65-125 | 50 | 20 | 67 | φ80 | φ65 | 4 | 5.5 |
| 10 | IH80-65-160 | 50 | 32 | 65 | φ80 | φ65 | 4 | 11 |
| 11 | IH80-50-200 | 50 | 50 | 63 | φ80 | φ50 | 4 | 15 |
| 12 | IH80-50-250 | 50 | 80 | 57 | φ80 | φ50 | 4.5 | 30 |
| 13 | IH100-80-125 | 100 | 20 | 73 | φ100 | φ80 | 5 | 11 |
| 14 | IH100-80-160 | 100 | 32 | 71 | φ100 | φ65 | 5 | 15 |
| 15 | IH100-65-200 | 100 | 50 | 66 | φ100 | φ65 | 5 | 30 |
| 16 | IH100-65-250 | 100 | 80 | 64 | φ125 | φ80 | 5 | 55 |
| 17 | IH125-80-160 | 160 | 32 | 72 | φ125 | φ100 | 6 | 30 |
| 18 | IH125-100-200 | 200 | 50 | 67 | φ100 | φ80 | 5 | 55 |
| N | Model | Rev=1450r/min Medium density=1000kg/m³ | ||||||
| Flow | Pump head | η | Inlet | Outlet | Npsh | Power | ||
| (m³/h) | (m) | (%) | (mm) | (mm) | (m) | (kw) | ||
| 1 | IH50-32-125 | 6.3 | 5 | 45 | φ50 | φ32 | 3 | 0.55 |
| 2 | IH50-32-160 | 6.3 | 8 | 40 | φ50 | φ32 | 3 | 0.55 |
| 3 | IH50-32-200 | 6.3 | 12.5 | 33 | φ50 | φ32 | 3 | 1.1 |
| 4 | IH50-32-250 | 6.3 | 20 | 30 | φ50 | φ32 | 5 | 1.5 |
| 5 | IH65-50-125 | 12.5 | 5 | 55 | φ65 | φ50 | 3.5 | 0.55 |
| 6 | IH65-50-160 | 12.5 | 8 | 51 | φ65 | φ50 | 3.5 | 1.1 |
| 7 | IH65-40-200 | 12.5 | 12.5 | 46 | φ65 | φ40 | 3.5 | 1.5 |
| 8 | IH65-40-250 | 12.5 | 20 | 43 | φ65 | φ40 | 3.5 | 3 |
| 9 | IH80-65-125 | 25 | 5 | 64 | φ80 | φ65 | 4 | 1.1 |
| 10 | IH80-65-160 | 25 | 8 | 62 | φ80 | φ65 | 4 | 1.5 |
| 11 | IH80-50-200 | 25 | 12.5 | 57 | φ80 | φ50 | 4 | 2.2 |
| 12 | IH80-50-250 | 25 | 20 | 53 | φ80 | φ50 | 4.5 | 4 |
| 13 | IH100-80-125 | 50 | 5 | 64 | φ100 | φ80 | 4.5 | 1.5 |
| 14 | IH100-80-160 | 50 | 8 | 68 | φ100 | φ80 | 5 | 2.2 |
| 15 | IH100-65-200 | 50 | 12.5 | 64 | φ100 | φ65 | 5 | 4 |
| 16 | IH100-65-250 | 50 | 20 | 62 | φ100 | φ65 | 5 | 7.5 |
| 17 | IH125-80-160 | 80 | 8 | 69 | φ125 | φ80 | 5 | 4 |
| 18 | IH125-100-200 | 100 | 12.5 | 64 | φ125 | φ100 | 6 | 7.5 |
| 19 | IH125-100-250 | 100 | 20 | 63 | φ125 | φ100 | 6 | 15 |
| 20 | IH125-100-315 | 100 | 32 | 60 | φ125 | φ100 | 3 | 18.5 |
| 21 | IH150-125-250 | 200 | 20 | 67 | φ150 | φ125 | 7 | 22 |
| 22 | IH150-125-315 | 200 | 32 | 65 | φ150 | φ125 | 7 | 45 |
| 23 | IH150-125-400 | 200 | 50 | 61 | φ150 | φ125 | 7 | 75 |
| 24 | IH200-150-250 | 400 | 20 | 69 | φ200 | φ150 | 7.5 | 55 |
| 25 | IH200-150-315 | 400 | 32 | 68 | φ200 | φ150 | 7.5 | 75 |
| 26 | IH200-150-400 | 400 | 50 | 63 | φ200 | φ150 | 7.5 | 110 |
