UHB-ZK corrosion and wear resistant pump

UHB-ZK corrosion and wear resistant pump

UHB-ZK corrosion and wear resistant pump

UHB-ZK corrosion and wear resistant pump
TECHNICAL DATA
Material: UHMW-PE/HT200
DN: 25mm-300mm
PN: 16bar
Q: 3.6m³/h-1000m³/h
H: 5m-80m
T: -20°C-120°C
P: 0.75kw-250kw

Send E-mail:xiaoyun@jnhgbf.com

Join Us On Whatsapp:Click it to Join in

General Overview

General Overview

  • UHB – ZK corrosion resistant mortar pump referred to as “UHB – ZK mortar pump” for the cantilever type single-stage, single-suction corrosion resistant pump, its flow components made of steel lining ultra-high molecular weight polyethylene with strong corrosion resistance, excellent wear resistance, creep resistance, resistance to environmental stress cracking), at the same time, use a metal matrix structure, improve the ability of product under pressure.
  • UHB – ZK corrosion resistant mortar pump is designed according to the national standard, made of ultra-high molecular weight polyethylene engineering plastics has excellent corrosion resistance, but also has very good abrasion resistance and good impact resistance, can adapt to different working conditions of the pump, such as acid, alkaline cleaning liquid or slurry transportation, corrosive slurry, sewage, etc. The pump is corrosion resistant and wear resistant, the use range is very wide, especially suitable for corrosive medium with high solid content.
  • Uhb-zk wear-resistant mortar pump can adapt to a variety of different working conditions. For example: can not only transfer acid, alkali liquid or slurry, can also transport a variety of corrosive pulp smelting industry, can also transport sulfuric acid industry of all kinds of dilute acid, environmental protection industry of all kinds of sewage, etc. It can transport sulphuric acid with concentration below 80%, nitric acid and hydrochloric acid with concentration below 50%, slurry containing all kinds of acid, alkali and salt, corrosive mortar in rare metal smelting industry and mixed media in food and wine industry.

Applicable fields Model parameters

N Model Rev=2900r/min   Medium density=1000kg/m ³
Flow Pump head η Inlet Outlet Npsh Power Weight
(m³/h) (m) (%) (mm) (mm) (m) (kw) (kg)
1 UHB-ZK32-25-125 3.6 20 18 Ф32 Ф25 3 1.5 95
2 UHB-ZK32-25-160 3.6 32 13 Ф32 Ф25 3 2.2 105
3 UHB-ZK40-32-125 6.3 20 21 Ф40 Ф32 3 2.2 110
4 UHB-ZK40-32-160 6.3 32 25 Ф40 Ф32 3 3 110
5 UHB-ZK50-32-125 12.5 20 42 Ф50 Ф32 3 3 110
6 UHB-ZK50-32-160 12.5 32 40 Ф50 Ф32 3 4 120
7 UHB-ZK50-40-200 12.5 50 30 Ф50 Ф40 5 7.5 170
8 UHB-ZK65-50-125 25 20 53 Ф65 Ф50 3.5 4 130
9 UHB-ZK65-50-160 25 32 51 Ф65 Ф50 3.5 7.5 145
10 UHB-ZK65-50-200 25 50 46 Ф65 Ф50 3.5 11 210
11 UHB-ZK65-50-250 25 80 30 Ф65 Ф50 3.5 22 250
12 UHB-ZK80-65-125 50 20 56 Ф80 Ф65 4 7.5 150
13 UHB-ZK80-65-160 50 32 55 Ф80 Ф65 4 11 180
14 UHB-ZK80-65-200 50 50 49 Ф80 Ф65 4 18.5 265
15 UHB-ZK80-65-250 50 80 49 Ф80 Ф65 4 30 450
16 UHB-ZK100-80-125 100 20 57 Ф100 Ф80 4.5 15 240
17 UHB-ZK100-80-160 100 32 60 Ф100 Ф80 4.5 18.5 290
18 UHB-ZK100-80-200 100 50 56 Ф100 Ф80 5 30 440
19 UHB-ZK125-100-125 150 20 60 Ф125 Ф100 5.5 18.5 480
20 UHB-ZK125-100-160 150 32 58 Ф125 Ф100 5.5 30 520
21 UHB-ZK125-100-200 150 40 55 Ф125 Ф100 5.5 37 530
N Model Rev =1450r/min   Medium density=1000kg/m³
Flow Pump head η Inlet Outlet Npsh Power Weight
(m³/h) (m) (%) (mm) (mm) (m) (kw) (kg)
1 UHB-ZK50-32-125 6.3 5 37 Ф50 Ф32 3 0.75 80
2 UHB-ZK50-32-160 6.3 8 35 Ф50 Ф32 3 0.75 80
3 UHB-ZK50-40-200 6.3 12.5 35 Ф50 Ф40 5 1.5 115
4 UHB-ZK65-50-125 12.5 5 45 Ф65 Ф50 3.5 1.1 110
5 UHB-ZK65-50-160 12.5 8 43 Ф65 Ф50 3.5 1.1 115
6 UHB-ZK65-50-200 12.5 12.5 39 Ф65 Ф50 3.5 2.2 160
7 UHB-ZK65-50-250 12.5 20 37 Ф65 Ф50 3.5 4 240
8 UHB-ZK65-50-315 12.5 32 39 Ф65 Ф50 3.5 7.5 270
9 UHB-ZK80-65-125 25 5 48 Ф80 Ф65 4 1.5 130
10 UHB-ZK80-65-160 25 8 53 Ф80 Ф65 4 1.5 135
11 UHB-ZK80-65-200 25 12.5 45 Ф80 Ф65 4 3 170
12 UHB-ZK80-65-250 25 20 42 Ф80 Ф65 4.5 5.5 270
13 UHB-ZK80-50-315 30 32 39 Ф80 Ф50 5 7.5 295
14 UHB-ZK80-65-315 25 32 39 Ф80 Ф65 5 11 295
15 UHB-ZK80-65-400 25 50 35 Ф80 Ф65 5 22 480
16 UHB-ZK100-80-125 50 5 52 Ф100 Ф80 5 1.5 165
17 UHB-ZK100-80-160 50 8 55 Ф100 Ф80 5 2.2 220
18 UHB-ZK100-80-200 50 12.5 52 Ф100 Ф80 5 4 340
19 UHB-ZK100-80-250 50 20 50 Ф100 Ф80 5 7.5 390
20 UHB-ZK100-80-315 50 32 46 Ф100 Ф80 5 15 450
21 UHB-ZK100-80-400 50 50 42 Ф100 Ф80 5 22 520
22 UHB-ZK125-100-160 100 8 56 Ф125 Ф100 5 11 480
23 UHB-ZK125-100-200 100 12.5 54 Ф125 Ф100 5 15 500
24 UHB-ZK125-100-250 100 20 52 Ф125 Ф100 5 18.5 550
25 UHB-ZK125-100-315 100 32 49 Ф125 Ф100 5.5 30 680
26 UHB-ZK125-100-400 100 50 46 Ф125 Ф100 5.5 37 720
27 UHB-ZK150-125-200 200 12.5 56 Ф150 Ф125 5.5 22 720
28 UHB-ZK150-125-250 200 20 53 Ф150 Ф125 5.5 30 780
29 UHB-ZK150-125-315 200 32 48 Ф150 Ф125 6 45 850
30 UHB-ZK150-125-400 200 50 43 Ф150 Ф125 6 75 1100
31 UHB-ZK200-150-250 400 20 56 Ф200 Ф150 7 55 890
32 UHB-ZK200-150-315 400 32 59 Ф200 Ф150 7 75 1120
33 UHB-ZK200-150-400 400 50 62 Ф200 Ф150 7 110 1480
34 UHB-ZK250-200-250 650 20 68 Ф200 Ф150 7.5 75 1150
35 UHB-ZK250-200-315 650 32 66 Ф200 Ф150 7.5 110 1620
36 UHB-ZK250-200-400 650 50 65 Ф200 Ф150 7.5 132 1880
37 UHB-ZK300-250-315 1000 32 70 Ф300 Ф250 8 160 2150
38 UHB-ZK300-250-400 1000 50 66 Ф300 Ф250 8 250 2800
