Home > CHEMICAL PUMP > CQB heavy duty fluoroplastic magnetic pump
CQB heavy duty fluoroplastic magnetic pump

CQB heavy duty fluoroplastic magnetic pump

CQB heavy duty fluoroplastic magnetic pump

CQB heavy duty fluoroplastic magnetic pump
TECHNICAL DATA
Material: F46/HT200
DN: 25mm-100mm
PN: 16bar
Q: 6.3m³/h-100m³/h
H: 32m-50m
T: -20°C-200°C
P: 5.5kw-18.5kw

Send E-mail:xiaoyun@jnhgbf.com

Send Inquiry Get Latest Price
Join Us On Whatsapp:Click it to Join in

General Overview

General Overview

  • CQB heavy-duty fluorine lined magnetic drive pump is referred to as “CQB heavy-duty magnetic pump” for short. It adopts magnetic coupling drive, and there is no dynamic sealing point. Therefore, it is a plastic magnetic pump type that prevents the general shaft drive centrifugal pump from running, emitting, dripping and leaking.
  • CQB heavy-duty fluorine lined magnetic drive pump is made of fluoroplastics and high-purity industrial ceramics, which has excellent corrosion resistance and sealing performance. Therefore, this product is widely used in chemical industry, acid making, alkali making, smelting, rare earth, pesticide, dye, medicine, paper making, electroplating, electrolysis, pickling, radio, foil forming, scientific research institutions, national defense industry and other industries.
  • CQB heavy-duty fluorine lined magnetic drive pump can transport medium: transport any concentration of acid, alkaline, oil, rare and precious liquid, toxic liquid, volatile chemical medium. Especially the transportation of flammable, leaky and explosive liquid chemical medium.

Applicable fields Model parameters

N Model Rev =2900r/min   Medium density=1000kg/m³
Flow Pump head η Inlet Outlet Npsh Power Weight
(m³/h) (m) (%) (mm) (mm) (m) (kw) (kg)
1 CQB40-25-200F 6.3 50 25 φ40 φ25 4.5 5.5 100
2 CQB50-32-200F 12.5 50 32 φ50 φ32 3.5 7.5 150
3 CQB65-40-200F 20 50 48 φ65 φ40 4 11 180
4 CQB80-65-160F 50 32 60 φ80 φ65 4 11 180
5 CQB80-50-200F 50 50 60 φ80 φ50 4 18.5 195
6 CQB100-80-125F 100 20 62 φ100 φ80 5 11 180
7 CQB100-80-160F 100 32 56 φ100 φ80 5 18.5 220

Installation dimensions Size chart

N Model Installation dimensions
Outside and installing size Inlet flange size Exit flange size
L B S P W T H h f c a b n-φd k g i n-φt
1 CQB40-25-200F 760 615 380 35 390 350 420 240 95 40 150 110 4-Ф17.5 25 115 85 4-Ф13.5
2 CQB50-32-200F 760 615 380 35 390 350 420 240 95 50 165 125 4-Ф17.5 32 140 100 4-Ф17.5
3 CQB65-40-200F 935 800 420 120 490 440 440 260 99 65 185 145 4-Ф17.5 40 150 110 4-Ф17.5
4 CQB80-65-125F 915 800 420 120 490 440 460 260 99 80 200 160 8-Ф17.5 65 185 145 4-Ф17.5
5 CQB80-65-160F 936 800 420 120 490 440 460 260 99 80 200 160 8-Ф17.5 65 185 145 4-Ф17.5
6 CQB80-50-200F 1340 1270 840 215 490 440 460 260 99 80 200 160 8-Ф17.5 50 185 125 4-Ф17.5
7 CQB100-80-160F 1295 1250 740 108 490 440 480 260 100 100 220 180 8-M18 80 200 160 8-M18
