| TECHNICAL DATA | |
| Material: | F46/HT200 |
| DN: | 25mm-100mm |
| PN: | 16bar |
| Q: | 2.5m³/h-100m³/h |
| H: | - |
| T: | -20°C-200°C |
| P: | - |
Send E-mail:xiaoyun@jnhgbf.com
| N | Model/diameter | L | L1 | D | D1 | D2 | n-φd | H | B | L0 | weight/Kg |
| 1 | Q41F-10-C-20 | 140 | 62 | 105 | 75 | 55 | 4-Ф14 | 112 | 10 | 155 | 3.5 |
| 2 | Q41F-10-C-25 | 150 | 65 | 115 | 85 | 65 | 4-Ф14 | 122 | 12 | 160 | 4.8 |
| 3 | Q41F-10-C-32 | 165 | 75 | 135 | 100 | 75 | 4-Ф17.5 | 130 | 13 | 160 | 7 |
| 4 | Q41F-10-C-40 | 180 | 83 | 145 | 110 | 85 | 4-Ф17.5 | 140 | 14 | 220 | 8 |
| 5 | Q41F-10-C-50 | 200 | 100 | 160 | 125 | 100 | 4-Ф17.5 | 140 | 14 | 220 | 10 |
| 6 | Q41F-10-C-65 | 220 | 100 | 180 | 145 | 125 | 4-Ф17.5 | 170 | 15 | 250 | 15 |
| 7 | Q41F-10-C-80 | 250 | 120 | 195 | 160 | 135 | 8-Ф17.5 | 200 | 15 | 300 | 20 |
| 8 | Q41F-10-C-100 | 305 | 142 | 215 | 180 | 150 | 8-Ф17.5 | 210 | 19 | 350 | 29 |
| 9 | Q41F-10-C-125 | 325 | 140 | 245 | 210 | 185 | 8-Ф17.5 | 210 | 20 | 350 | 50 |
| 10 | Q41F-10-C-150 | 394 | 197 | 280 | 240 | 210 | 4-Ф23 | 250 | 24 | 390 | 65 |
