CMB wear resistant fluoroplastic magnetic pump

CMB wear resistant fluoroplastic magnetic pump

CMB wear resistant fluoroplastic magnetic pump

CMB wear resistant fluoroplastic magnetic pump
TECHNICAL DATA
Material: F46/HT200
DN: 20mm-125mm
PN: 16bar
Q: 2m³/h-200m³/h
H: 20m-80m
T: -20°C-200°C
P: 0.75kw-55kw

Send E-mail:xiaoyun@jnhgbf.com

Send Inquiry Get Latest Price
Join Us On Whatsapp:Click it to Join in

General Overview

General Overview

  • CMB anti-particle and anti-dry grinding fluoroplastic magnetic pump, ANSYSICEM+CFD, CFX finite element analysis, fluid visual simulation technology was used to design high-performance hydraulic model, pump body and impeller, impeller and isolation sleeve design with solid particle barrier ring structure, reduce particle wear.
  • The supporting shaft adopts non-cantilever supporting structure with fixed rotating shaft wide fulcrum, which avoids the trouble of shaft breakage of shaft driving rotor, and has better stability. The reinforced sleeve made of non-metallic material completely eliminates the damage caused by magnetic eddy current heating and improves the operation reliability.
  • PLUSSSiC composite ceramics manufacture sliding bearing components, which are not only resistant to wear of solid particles, but also can withstand empty operation for 30min under the condition of pumping. CMB(L) is designed with long suspension structure with bearings, which can prevent high temperature of medium from affecting motor operation.
  • The pump grain resistance, resistance to dry grinding, high efficiency and energy saving, stable running, quiet low vibration, high reliability, long life and other similar fluorine plastic magnetic pump incomparable advantages, break through the traditional fluorine plastic magnetic pump use restrictions, is strong corrosive, toxic, volatile, flammable and explosive, organic solvent and precious liquid ideal conveying equipment of environmental protection.

Applicable fields Model parameters

N Model Rev=2900r/min  Medium density=1000kg/m³
Flow Pump head η Inlet Outlet Npshr Power Weight
(m³/h) (m) (%) (mm) (mm) (m) (kW) (kg)
1 CMB25-20-125 2 20 24 ø25 ø20 2.0 0.75 35
2 CMB25-20-160 2 32 22 ø25 ø20 2.0 1.1 40
3 CMB25-20-200 2 50 20 ø25 ø20 2.0 2.2 65
4 CMB32-20-125 3.6 20 19 ø32 ø20 2.0 1.1 40
5 CMB32-20-160 3.6 32 27 ø32 ø20 2.0 1.5 50
6 CMB32-20-200 3.6 50 24 ø32 ø20 2.5 3 75
7 CMB40-25-125 6.3 20 36 ø40 ø25 2.5 1.5 45
8 CMB40-25-160 6.3 32 33 ø40 ø25 2.5 2.2 50
9 CMB40-25-200 6.3 50 29 ø40 ø25 2.5 5.5 95
10 CMB40-25-250 6.3 80 25 ø40 ø25 2.5 7.5 135
11 CMB50-32-125 12.5 20 47 ø50 ø32 2.5 2.2 50
12 CMB50-32-160 12.5 32 43 ø50 ø32 2.5 4 95
13 CMB50-32-200 12.5 50 40 ø50 ø32 2.5 7.5 125
14 CMB50-32-250 12.5 80 35 ø50 ø32 2.5 11 190
15 CMB65-50-125 25 20 55 ø65 ø50 2.5 4 90
16 CMB65-50-160 25 32 50 ø65 ø50 2.5 5.5 105
17 CMB65-40-200 25 50 45 ø65 ø40 2.5 11 160
18 CMB65-40-250 25 80 40 ø65 ø40 2.5 18.5 230
19 CMB80-65-125 50 20 54 ø80 ø65 3.0 5.5 80
20 CMB80-65-160 50 32 52 ø80 ø65 3.0 11 135
21 CMB80-50-200 50 50 46 ø80 ø50 3.0 18.5 190
22 CMB80-50-250 50 80 43 ø80 ø50 3.5 30 310
23 CMB100-80-125 100 20 63 ø100 ø80 3.5 11 140
24 CMB100-80-160 100 32 50 ø100 ø80 3.5 18.5 195
25 CMB100-65-200 100 50 46 ø100 ø65 3.5 30 310
26 CMB100-65-250 100 80 43 ø100 ø65 4.0 45 420
27 CMB125-80-160 160 32 60 ø125 ø80 4.0 30 360
28 CMB125-100-200 200 50 55 ø125 ø100 4.5 55 500
